Using the displays
OPM 520 en-GB 11
© Scania CV AB 2018, Sweden
To navigate between the instrument pages:
• You scroll between the instrument pages by
pressing on the right- or left-hand side of the
display. See illustration.
• You reach the first instrument page, by press-
ing the home key briefly. See illustration.
Note: A longer press on the home button (1
second) will open the main menu instead.
Select Page
You get to Select Page by pressing in the middle
of the display when on one of the instrument
pages.
In Select Page thumbnails of the instrument pag-
es and the Menu are shown. Select the instrument
page you wish to display by pressing the corre-
sponding thumbnail, or select Menu.
