Standard wander hose
The wander hose is used to suck up objects in areas that the sweeper is unable to access i.e. drain inlets, under benches, etc.
Using the standard wander hose
Wear appropriate PPE.
1. Vehicle OFF. Neutral gear selected. Handbrake On. Sweep mode and
multi-function lever OFF.
2. Remove the wander hose q attached to the rear door.
3. Remove either of the blanking plate w from the rear door aperture and stow
on the spare fasteners below.
4. Attach the wander hose over the exposed aperture e, using the captive
fasteners r.
5. Sweep mode ON . Suction fan ON .
6. For situations requiring maximum suction power i.e. when removing
stubborn objects, etc, select fan boost .
7. When finished, turn all controls OFF and return the wander hose to its stored
position, replace the blanking plate.
