Mistral Operating Instructions
Part No. SCAZ037980 v6.0.2 28 E&OE
Auxiliary engine
Wear appropriate PPE.
Ensure that the hopper safety prop has deployed correctly when working beneath a raised hopper. failure to do so could result in serious injury.
When mounting the chassis always use the access steps and tread plates. Ensure they are free from contamination that may cause them to become slippery. Always
wear suitable footwear with clean and dry soles.
Ensure that the sweeper is on a flat and level surface with the auxiliary engine stopped for a suitable period, to allow the oil to return to the sump.
The auxiliary engine is the responsibility of the operator, as is the chassis engine. The following instructions should be followed as detailed in the maintenance schedule on
page 26 and in the manufacturer’s recommendations.
Raise the hopper in accordance with the instructions detailed on page 13.
Engine oil
Engine oil: (15w/40).
Allow time for the added oil to drain through to the sump
before re-checking the level.
Topping up
1. Remove the dipstick q from the holder.
2. Wipe clean with a lint-free cloth.
3. Replace in it holder. Remove again and check the oil level.
4. The oil should never fall below the minimum level or
exceed the maximum level shown on the dipstick.
5. Remove the filler cap w and pour oil through the opening
until the correct level is maintained.
6. Replace filler cap.
