General Information
Typical weights, dimensions and capacities
Gross vehicle weight (GVW) * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 to 15 tonne
Overall height (hopper lowered) * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3000 to 3500mm
Maximum height (hopper raised) * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4500mm
Overall length * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6000mm
Overall width (brushes stowed) * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2500mm
Gross hopper volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6.2m
3
Tank capacities *
Chassis fuel tank *. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Typically 100 to 150 litres
Auxiliary engine fuel tank * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117 to 135 litres
Hydraulic oil tank * . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51-56 litres
Water tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1250 litres
Noise levels
In cab . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Between 70 - 84 dB(A) dependent on operating speed
External . . . . . . . . . . . . . . . . Maximum LWA of 114 dB(A) in accordance with directive 2000/14/EC
Vibration
Description. . . . . . . . . All dynamic prime moving components are resiliently mounted to minimise
vibrations. In accordance with 2006/42/EC as amended
Whole body . . . . . . . . . . . . . . . . . . . . . . . . . . Equipment does not exceed 0.5 m/s² (RMS, weighted)
Hand & Arm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Equipment does not exceed 2.5 m/s² (VTV)
* Dimensions given are for general guidance only and are subject to chassis type used. For specific
chassis related details please contact the Sales Department.
Cummins auxiliary engine
This manual does not cover the Cummins QSB 3.3 Tier 3A auxiliary engine. Information such as the
User Manual is available as a free download from the following web site:
https://quickserve.cummins.com/info/index.html
Identification plates
The SERIAL NUMBER PLATE is located on the rear face of the left hand suction nozzle spigot.
The Serial Number will comprise four numerical digits only (for example 5843).
For the location of the vehicle’s VIN PLATE and CHASSIS NUMBER, refer to the chassis
manufacturers’ documentation.
Limitations of use
The Scarab Mistral is classified as truck-mounted heavy-duty suction road sweeper and, as such, is
intended only for operation in the sweeping and associated roles for which it has been expressly
designed.
Applicability
This manual covers the operating requirements of the Scarab Mistral sweeper with the CANbus 3
operating system.
Warnings
Starting engine
Voltage sensitive components.
Do not use a boost start/super start. A boosted start will burn out the vehicles
electronic control nodes.
If batteries are not charged then always use a fresh set.
Electrical equipment
CB Radios and other electrical equipment used in the sweeper should be
properly suppressed (EMC) to prevent the possibility of interference in the
sweeper electronic system.
Towing
Serious damage to the transmission could result if the vehicle is towed while
gearbox is engaged.
If towing is necessary, it is imperative that the prop shaft is disengaged from the differential
or that the rear wheels are clear of the ground before making any attempt to tow the vehicle
