24 I 72
Limit the noise and vibration to a minimum!
• Use only faultless device.
• Maintain and clean the unit regularly.
• Customize the way you work on the equipment.
• Do not overload the device.
• If you unsure, bring the device to a service station
• Switch off the unit if you do not use it.
7. Before starting up
m ATTENTION!
Always check before starting the engine:
• Check the fuel level and top it up if necessary
- the tank (21) should be at least half lled
• Make sure that the machine has sufcient ventila-
tion
• Make sure that the ignition cable (25) is secured
to the spark plug (13)
• Condition of the air lter
• Condition of the fuel lines
• The external bolt connections for tightness
Filling with fuel
Recommended fuel
Fill the only clean fuel with min. 90 octane and max.
5% bio-ethanol content in the fuel tank (21).
m NOTE
Fill tank to no more than 12.5mm (1/2”) below the
bottom of the ller neck to provide space for ex-
pansion.
Use only fresh and clean fuel.
m Attention!
Water or impurities in the petrol damage the fuel sys-
tem.
Tank volume: 3,6 litre
m Refuel in a well-ventilated area with the
stopped engine. If the engine has been running,
allow it to cool rst. Never refuel the engine in-
side a building where gasoline fumes may reach
ames or sparks.
Petrol is highly ammable and explosiv. You can
get burns or other serious injuries when handling
fuel.
• Switch off the engine and keep it away from heat,
sparks and ames.
• Refuelling only outdoors.
• Immediately clean up spilled petrol.
8. Functions and controls
Engine switch (Fig.1/Pos.2)
The engine switch (2) enables and disables the igni-
tion system.
The engine switch (2) must be in the “ON” position
for the engine to run.
The engine switch (2) must be in the “OFF” position
to stop the engine.
If you obtain aid please give the following infor-
mations:
1. Where did it happen
2. What happend
3. How many injured
4. Type of injury
5. Who is reporting!
6. Technical data
Engine 6,5 PS
Transmission 3F+1R
Load capacity 300 kg
Box Length 912 mm
Box width 650 mm
Box Depth 560 mm
Weight 160 kg
Engine Type 4-stroke engine
Idle speed 1400 1/min.
maximum RPM 3600 1/min.
Motor Starters Recoil starter
Fuel
Unleaded fuel octane num-
ber 90 and max. ethanol of
5%
Fuel tank capacity 3,6 l
Required engine oil SAE 10W-30
max. slope 12°
Max. Oil tank capac-
ity
0,6 l
Subject to techcnical modications!
Information concerning noise emission measured ac-
cording to relevant standards:
Sound pressure L
pA
= 84,7 dB(A)
Sound power L
wA
= 100 dB(A)
Uncertainty K
pA
= 3,0 dB(A)
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Vibration Left Steering Lever A
hv
= 3,92 m/s
2
Vibration Right Steering Lever A
hv
= 9,92 m/s
2
Uncertainty K
PA
= 1,5 m/s
2
The specied vibration emission value has been
measured according to a standardised testing proce-
dure and can be used for comparison of one electric
tool with another.
The specied vibration emission value can also be
used for an initial assessment of the load.
m WARNING
The vibration emission value can vary from the spec-
ied value during the actual use of the electric tool,
depending on the type and the manner in which the
electric tool is used.
Try to minimise stress from vibrations as low as pos-
sible. Some examples of means for reducing the vi-
bration stress are wearing gloves while using the
tool and limiting work time. In the process all parts
of the operating cycle must be taken into account
(such as times in which the electric tool is switched
off or time in which it is switched on, but is not run-
ning under a load).
