7 Parameter menu
Operating Manual Linear ACTUSAFE CMFS(L)
OM-ENGLISH-Failsafe-Linear-16xx-V2.00-2022.03.03
continued from previous page
Menu item Sub-menu item poss. setting Notes / comments
P10.12 Bin. Output Output 6 Konf. see Output 1 conf.
P10.13 Bin. Output Output 7 see Output 1
P10.14 Bin. Output Output 7 Konf. see Output 1 conf.
P10.15 Bin. Output Output 8 see Output 1
P10.16 Bin. Output Output 8 Konf. see Output 1 conf.
CAUTION: When using the parameters torque-dependent OPEN or torque-dependent CLOSED (see section
7.1, page 42, items P1.3 and P1.4), the actuator will only be open or closed when the set torque and the asso-
ciated end position is reached. If the end position is not reached, a torque error is reported (see section 6.2.2,
page 35).
NOTE: For optional functions such as a relay board or virtual outputs please refer to the corresponding IOM.
