Schlage M422 - Reorient Magnet in One Lock; Place Template and Mark Holes

3
1b
Reorient Magnet in One Lock
• Remove screws, wiring cover and end blocks.
• Rotate magnet, end blocks and wiring cover as shown, then reassemble.
End Block
Magnet
End Block
Magnet
Wiring Cover
1c
Place Template and Mark Holes
• Place template on top centerline of doors.
• Mark holes and prepare them per template.
