Page 8 (Attach Magnets to Mounting Brackets)
Schlage M422 - Attach Magnets to Mounting Brackets; Install Joining Block into Lock; Secure Locks with Four Screws
12 pages
Manual
Save Page as PDF
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
8
6
A
TT
A
CH MA
GNETS
T
O MOUNTING BRA
CKETS
6a
Slide One Magnet onto Brac
ket
OUTSIDE
6b
Install Joining Block into Loc
k
6c
Slide Second Magnet onto Brac
ket
•
Align with joining bloc
k.
6d
Secure Locks with Four (4) Scre
ws
Actual Size
