9
7 CONNECT WIRING TO BOARD (STANDARD MODEL)
7a
Review Wiring Connections
TB1
Mag Lock Board
DC (+)
DC (-)
From Magnet
TB1
Mag Lock Board
DC (+)
DC (-)
From Magnet
DC (+) DC (-)
7b
Connect Wires to Boards
From Door Frame
DC Power Wires
From Magnet
7c
Install Covers
