1.3 Illustration of the DTF PowDR
1
2
3
4
5
6
7
8 9
10
11
12
13
1. Main switch
2. Power wire with the plug
3. Emergency switch
4. Work control led
5. Mode switch (DTF PowDR MODE/DRYER ONLY)
6. Control panel
7. Power socket of the powder dispenser
8. Powder chamber
9. Button for manual powder dispensing from the
powder dispenser
12. Positioners for foil entry into the powder zone
10. Top cover of the powder zone
11. Powder dispenser with motor (powder zone)
13. Rolling system with a brake
25. Powder zone cover sensor
14. Heating zone
17. Cooling zone
23. Conveyor belt
16. Positioners of foil’s output
15. Heating lamps
19. Locking knobs for adjusting the width of the roll
18. Winder (foil winder)
21. Switch winder
22. Switch of the cooling zone
26. Heating zone sensor
20. Power socket of the cooling zone
24. Adjustable covers of the heating zone
14
15
16
18
19
20
21
22
23
24
POLSKI
26
ENGLISH
20
17
Version 23.05
