5.3 Replacement of the temperature fuse
7. Put on the lower part of the cover of the gelling zone, fscrew it with the screws removed in step 1.
4. Carefully remove the wires from the fuse (images 3-4),
The temperature fuse is located in the top cover of the gelling zone. If it needs to be replaced, the device must be cooled down, turned off, and the
plug removed from the power socket. To replace the temperature fuse, it is necessary to:
3. Unscrew the screw holding the fuse (image 2),
1. Unscrew the 8 screws, marked with circles (image 1),
5. Put the wires on the new fuse (images 5-6),
2. Remove the lower part of the cover of the gelling zone, put it on the conveyor belt of the device,
6. Screw on the new fuse (image 7),
5.4 Replacement of the lamps
The lamps are located in the cover of the heating zone. Before replacing them, make sure the machine is turned off and disconnected from
the power supply.
4. Photo of correctly removed lamp (image 7).
2. Pull the insulation off the wire (image 2), and then disconnect it on both sides of the lamp (images 3-4).
Attention! Use cotton gloves to replace the lamps. Do not touch the lamps with bare hand, greasing the lamp risks failure.
To replace the lamp it is necessary to:
1. Open the top cover (image 1).
3. By leveraging the plate, pull it out of its mounting on both sides (images 5-6).
1 2 3 4
5 6 7
1 2 3
4 5 6
7
ENGLISH
30
Version 23.05
