Design and description
06.00 | DRG | Assembly and operation manual | en | 389041 17
4 Design and description
4.1 Design
Radial gripper DRG
1 Hose-free direct connection at the base
2 Main air connections
3 Base jaw
4 Thread for control cams
5 Case
6 Groove for magnetic switch
4.2 Characterization
Sealed 180° angular gripper for use in contaminated
environment.
