Assembly
06.00 | DRG | Assembly and operation manual | en | 389041 27
3. Clamp the magnetic switch in this position in the groove by
tightening the set-screw (4).
4. Open the product and close it again in order to test its
function.
Part gripped (O.D. gripping):
1. Clamp the part to be gripped.
2. Push the magnetic switch (2) into the groove towards the
middle of the gripper until it switches.
3. Clamp the magnetic switch in this position in the groove by
tightening the set-screw (4).
4. Open the product and close it again in order to test its
function.
5.4 Setting the opening angle limits
Position of the item numbers }7.6 [/38]
5.4.1 DRG 44 - 80
To set the required opening angle, use the adjusting screw (70,
71, 72) and nut (73) from the accessory pack Accessories pack.
1. Switch off the compressed air supply and leave the gripper
unpressurized in the "Closed" position.
2. Unscrew the locking screws (14).
3. Turn the nut (73) onto the adjusting screw (70, 71, 72).
4. Turn the nut (74) onto the adjusting screw (70, 71, 72).
5. Screw in the adjusting screw (70, 71, 72), instead of the locking
screw(14), into the cover (10) and set the required opening
angle.
6. Using the nut (73), tighten the adjusting screw (70, 71, 72).
7. Test the set opening angle by actuating the gripper with
compressed air.
If necessary, switch off the compressed air supply and repeat
steps 5 and 6.
NOTE
l
The further the adjusting screw (70, 71, 72) is screwed into the
cover, the smaller the opening angle becomes.
l
If the adjusting screw (70, 71, 72) protrudes too far over the
cover, then use a shorter screw from the accessory pack (3
different lengths) or shorten the adjusting screw as required.
