Technical data
11.00 | EGP | Assembly and Operating Manual | en | 389476
17
3 Technical data
3.1 Connection data
3.1.1 EGP 25
Designation EGP
25 25-S
Supply voltage [VDC]
Min. [VDC]
Max. [VDC]
24
21.6
26.4
Min. Supply current power
supply unit [A] *
1.0
Max. Current input [A]** 1.0
Gripping force [%] 50 100 100
Current input in blocked
state [A] ***
0.07 0.14 0.14
Integrated electronic control unit
Communication interface Digital I/O
Number of digital inputs/
outputs 2/2
* minimum supply current for reliable operation of product
** maximum current input in the acceleration phase (max. t = 50 ms)
*** Current input in blocked state (in gripper end position or
while gripping a workpiece) with active command "Open
Gripper" or "Close Gripper"
More technical data is included in the catalog data sheet.
Whichever is the latest version.
