Assembly
32
11.00 | EGP | Assembly and Operating Manual | en | 389476
5.3 Mounting the sensor
NOTE
Observe the assembly and operating manual of the sensor for
mounting and connecting.
The product is prepared for the use of sensors.
• For the exact type designations of suitable sensors, please see
catalog datasheet and Overview of sensors [
}
32].
• For technical data for the suitable sensors, see assembly and
operating manual and catalog datasheet.
– The assembly and operating manual and catalog datasheet
are included in the scope of delivery for the sensors and are
available at schunk.com.
• Information on handling sensors is available at schunk.com or
from SCHUNK contact persons.
5.3.1 Overview of sensors
Designation
EGP
25 40 50 64
Inductive proximity switch IN 40 X X X X
Flexible position sensor FPS-S 13 X X X
Optical distance sensor OAS X X X X
5.3.2 Mount inductive proximity switch IN 40
The inductive proximity switches are mounted on the plug
connectors side of the product. If the cable routing on this side is
unfavorable for the customer-specific application, the inductive
proximity switches can be mounted on the opposite side.
The screw heads and the spacer sleeve serve the purpose of
querying by the inductive proximity switches and are mounted on
the gripper fingers.
