Assembly
11.00 | EGP | Assembly and Operating Manual | en | 389476
27
5 Assembly
5.1 Installing and connecting
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
• Before starting any work on the product: Switch off the power
supply and secure against restarting.
• Make sure, that no residual energy remains in the system.
NOTE
Ensure sufficient heat dissipation using the customer's mounting
surface.
Mount the product so that sufficient cooling is guaranteed. The
size of the cooling surface depends on the application. Avoid
exposure to additional heat e.g. caused by attachments or by the
attached axle.
A temperature malfunction may occur if the product reaches
excessively high temperatures.
"Digital I/O" variant
Ø Check the evenness of the mounting surface, Mechanical
connection [
}
28].
Ø Screw the product to the machine/system, Mechanical
connection [
}
28].
✓ If necessary, use appropriate connection elements (adapter
plates).
✓ Use centering sleeves from the enclosed accessory pack.
✓ Observe the permissible depth of engagement.
✓ Observe the tightening torque for the mounting screws.
Ø Secure the gripper fingers to the base jaws,
Mechanical connection [
}
28].
Ø Place the voltage supply and control cable on the M8 connector and
screw the threaded ring tightly by hand, Digital I/O variant [
}
22].
Ø Adjust gripping force if necessary, Adjust gripping force [
}
37].
Ø Mount the sensor, Mounting the sensor [
}
32].
NOTE
For further information on controlling the product, see section
Start-up [
}
37].
