Design and description
10 01.00 | FPS-F5 | Assembly and Operating Manual | en | 15959911
4 Design and description
4.1 Structure
Control and display panel
Item Designation Item Designation
1 Sensor connection 4 Voltage supply connection
and digital inputs and
outputs
2 Save button 5 RS 232 interface and
coding pin
3 LED output signals 6 Selection button
The control and display panel is covered by a plastic lid.
