5 Assembly and settings
NOTE
The assembly instructions in this chapter are generally
applicable.
Module-specific assembly instructions for the sensor can be
found in the Assembly and Operating Manual for the module,
which can be downloaded at schunk.com
5.1 Mechanical connection
CAUTION
Property damage due to incorrect bending radius!
The product may get damaged if the cable's bending radius is
less than the minimum.
l
Static: 10 times the cable diameter.
l
Dynamic: 15 times the cable diameter.
CAUTION
Risk of damage to the sensor during assembly!
l
Observe the maximal tightening torque.
NOTE
l
Do not use the sensor as a safety component.
l
Do not pull on the cable of the sensor.
l
Secure the cable and connection plug so that they are not
taught and cannot move during operation.
l
Do not exceed the permitted bending radius of the cable.
l
Do not allow the sensor to come into contact with hard
objects and chemicals (e.g., nitric acid, chromic acid and
sulfuric acid).
The sensor is an electronic component that can be sensitive to
high-frequency interference or electromagnetic fields.
l
Check whether there is sufficient distance between the sensor
and sources of interference and their supply cables.
Ferromagnetic components, e.g. adapter plates made of
construction steel, change the switching positions of the sensor.
