Assembly
26 14.00 | GSM-P | Assembly and Operating Manual | en | 389104
"A" - "D" are main connections, "a" - "d" are direct
connections
Connection Function
Hose connection A Swivel toward 180° or 90°
position
Hose-free direct connection a
Hose connection B Swivel toward 0° position
Hose-free direct connection b
Hose connection C Move gripper into »OPEN«
position
Hose-free direct connection c
Hose connection D Move gripper into »CLOSED«
position
Hose-free direct connection d
Connections “C” and “D” for the modules with a base cross
section of 25x25 are slightly offset from center
If direct connections "a" – "d" are used, use the locking screws
included in the accessory pack for the corresponding main
connections "A" – "D".
If air connections "a" – "d" are used, ensure sufficient
throttling, which can be set by means of exhaust air throttling.
To do this, the throttle reductions for the main connections,
which are designed for a medium load, can be attached to the
adapter plate, for example.
l
Open only the air connections that are needed.
l
Close unused main air connections using the screw plugs from
the enclosed pack.
l
For a hose-free direction connection, use the O-rings from the
enclosed pack.
