Commissioning
40 14.00 | GSM-P | Assembly and Operating Manual | en | 389104
6.2 Setting the speed
CAUTION
Material damage due to erroneous settings!
If the end position is approached too hard, the product may be
damaged.
l
Adjust exhaust throttle valve and shock absorber so that the
movement is braked smoothly.
1. Close exhaust throttle valve completely.
2. Open exhaust throttle valve until the product starts to move.
3. Continue to open the exhaust throttle valve incrementally
until the movement decelerates smoothly.
ð If the speed is too low, the product will brake too soon
and the end position will be reached too slowly.
ð If the speed is too high, the product will impact against
the end position and the shock absorber will be
overloaded.
6.3 Restart after long standstill
During a longer standstill, no compressed air may be applied to
the product.
If issues occur during the restart process, see }7.2 [/42]
