Maintenance
46 14.00 | GSM-P | Assembly and Operating Manual | en | 389104
8.4 Screw tightening torques
Position of the item numbers, }8.12 [/57]
GSM-P Item 110 Item 111 Item 112 Item 115
32 2.7 Nm 2.7 Nm 0.7 Nm 5.8 Nm
40 5.8 Nm 5.8 Nm 0.7 Nm 5.8 Nm
50 5.8 Nm 12 Nm 0.7 Nm 5.8 Nm
64 6 Nm 12 Nm 1.3 Nm 12 Nm
Tab.: Screw tightening torquesGSM-P
Rotary
grippin
g
module
Item
121/124
Item
133
Item
140
Item
231
Item
232
GSM-
P-32/-
P-40
Basic
size
40x40
1.2 Nm - 2 Nm 6 Nm 3 Nm
GSM-
P-50/-
P-64
Basic
size
64x64
2.0 Nm - 4 Nm 10 Nm 6 Nm
Tab.: DKM screw tightening torques
Rotor drive Item 101 Item 104
FAN 40 1.3 Nm
FAN 64 3.1 Nm
Tab.: Tightening torques for screws FAN
