Maintenance
11.00 | PGN | Assembly and Operating Manual | en | 389286
43
6.5.2 Screw tightening torques
Position of the item numbers Assembly drawing [
}
44]
Item
PGN
50
[Nm]
64
[Nm]
80
[Nm]
100
[Nm]
125
[Nm]
160
[Nm]
200
[Nm]
300
[Nm]
380
[Nm]
10 0.8 5.8 12 12 20 49 75 75 75
11 1.9 1.9 4.9 4.9 2.9 1.9 4.9 4.9 10
39 2.7 14 24 24 57 67 116 116 200
40 2.2 2.2 4.9 4.9 6.0 4.9 10 10 10

SCHUNK PGN Series Specifications

General

Actuation	Pneumatic
Number of Fingers	2
Material	Aluminum
Type	Parallel gripper
Holding force without pressure	0 N
Operating pressure	4 bar - 8 bar
