Assembly and installation
04.00 | SVH | Assembly and Operating Manual | en | 389734 19
5 Assembly and installation
WARNING
Risk of injury due to unexpected movements!
If the power supply is switched on or residual energy remains in
the system, components can move unexpectedly and cause
serious injuries.
l
Before starting any work on the product: Switch off the power
supply and secure against restarting.
l
Make sure, that no residual energy remains in the system.
CAUTION
Risk of damage when using screws that are too long!
l
Observe the maximum depth of engagement permitted for
the mounting screws.
CAUTION
Risk of damage when using unsuitable connecting elements!
l
SCHUNK recommends using SCHUNK connecting elements.
CAUTION
Risk of operational malfunction due to torn or pinched lines!
If electrical lines are too short or installed incorrectly, they may
become pinched or torn by the movement of the module.
l
Factor in operating movements when connecting the module.
CAUTION
Risk of operational malfunction due to short circuit or incorrect
connections!
l
Before connecting, ensure that the electrical lines are
deenergized.
l
Be sure to distribute the clamps correctly.
