Assembly and installation
20 04.00 | SVH | Assembly and Operating Manual | en | 389734
CAUTION
Permanent damage to the electronics possible!
l
If the power supply is separated, carry out potential
equalization between the two supply voltages (join the
grounds).
l
Only the positive pole may be switched off; the GND motor
cable must always remain connected.
NOTE
A power supply unit must be used that is capable of supplying
sufficient power for the product. Make sure the dimensions of
the cable cross-section are sufficient when installing the cables.
5.1 Mounting to a robot or moving unit
CAUTION
Risk of injury due to the workpiece falling!
In the event of a power failure or incorrect gripping process, the
gripped workpiece may fall.
l
Ensure that the gripping process is performed correctly with a
suitable gripping force.
l
Keep distance.
l
Wear safety boots.
CAUTION
Risk of injury if the product is torn from the robot arm or
moving unit!
If the mounting process has not been performed properly, the
product may come loose from the robot arm.
l
Mount the flat change system properly.
l
Tighten the lateral cylindrical screw to the clamping ring with
a spanner wrench.
