Technical data
04.00 | SVH | Assembly and Operating Manual | en | 389734 15
3 Technical data
3.1 Outer dimensions
Dimensions
The right and left hands are laterally inverted. The dimensions
are identical.
3.2 Basic data
Designation SVH
Right Left
Overall length [mm] 242.5
Hand width [mm] 92
Max. finger width [mm] 19.6
Weight [kg] 1.3
IP rating 20
Min. ambient temperature [°C]
Max. ambient temperature [°C]
10
40
Noise emission [dB(A)] <60
Number of joints 20
