48
FIGURE 3-10: TUBE CALIBRATION RESULTS
TABLE 3-1: TUBE CALIBRATION GUIDE
MODULE
FX1 FX2 FX3 FX4 FX5
Deep Inflation Rl value
(cmH2O.s/mL) should exceed
2000 1125 600 370 260
If your values are not acceptable, confirm that all tubing connections are tight and re-perform
the calibration making sure the cannula is tightly blocked during the closed calibration. If you
continue to get values that are not within acceptable range, please contact SCIREQ Technical
Support.
The importance of proper calibration cannot be overstated. Any errors or inaccuracies
introduced during calibration become part of the data until the next calibration is performed.
15)
The software prompts you to start default ventilation. If you plan to connect a subject right
away, select
Yes
. Please refer to the
flexiVent-Specific Features
section of the
flexiWare
User Manual for information on customizing ventilation patterns.
