SPECIFICATION CONDITIONS MIN TYP MAX UNITS NOTES
Power supply
(Main
flexiVent
FX
power entry)
Kycon, DC Power
connector, 4 pin DIN
R7B female, Snap &
Lock on
flexiVent
1 qty
IEC320C14 male on
power supply
1 qty 4
Notes:
1 See Table A-2.
2 4 subjects can be studied with the extension for multiple subjects.
3 The FX base unit ships with one module attached; additional modules ship separately.
4 Appropriate AC power cord typically provided only to direct SCIREQ clients in North
America. Clients served by a distribution partner may receive cords through their
distributor. Direct clients outside of North America will need to obtain an appropriate cord.
5 Ventilation tidal volume is configurable in the software. Tidal volume is limited by the
stroke volume of the module in use, so refer to Table A-2 for details.
6 The I:E ratio in the software is expressed as a percentage of the exhalation time that the
inhalation time lasts, e.g. the default 2:3 I:E ratio is expressed as 67%, a 1:1 ratio is expressed
as 100%.
7 Linearity of the transducers is only guaranteed up to ± 76.2 cmH
2
O
8 The lower limit for computer-controlled PEEP is on the order of 0.25-0.5 cmH
2
O and may
vary slightly from one configuration to the next. The minimum of 0 cmH
2
O reflected in the
table is achievable if the option for PEEP control is set to ‘External’ in the ventilation
pattern definition dialogue.
9 Alternate sampling frequencies are available and included in some pre-configured
templates (e.g. those for use with the negative pressure forced expiration hardware). Use
of alternate sampling frequencies may require increased computer RAM and/or
modifications to the real time data view. Please contact Technical Support for more details.
