Appendix V: Replacement Parts
112
continued from previous page
Part Number Part Application Description
Quantity
in 19plus
V2
60021
Spare battery end cap
hardware and o-rings
O-rings and hardware, including:
• 30145 Screw, 6-32 x
1
/2 Phillips-head, stainless steel (secures battery cover plate
to battery posts)
• 30242 Washer, #6 flat, stainless steel (for screw 30145)
• 30816 Parker 2-234E603-70 (battery end cap to housing piston seal,
sensor end cap to housing seals)
• 30090 Parker 2-153N674-70 (battery end cap to housing face seal)
-
50274 Spare o-ring kit
Assorted o-rings, including:
• 30816 Parker 2-234E603-70 (battery end cap to housing piston seal, sensor end
cap to housing seals)
• 30090 Parker 2-153N674-70 (battery end cap to housing face seal)
• 30507 Parker 2-206N674-70 (each end of conductivity cell)
• 30802 Parker 2-110DUR070, ethylene (titanium conductivity cell tray face seal,
groove surface)
• 30809 Morrison seal, .047” hole, NIT (temperature probe Morrison seal)
• 30072 Parker 2-017N674-70 (bulkhead connector seal)
• 30070 Parker 3-904N674-70 (pressure sensor mounting seal)
• 30087 Parker 2-232N674-70 (buffer for top retainer for PCB sandwich assembly)
• 30801 Parker 5-374E603-70 (base of battery bulkhead seal)
-
50273 Spare hardware kit
Assorted hardware, including:
• 30163 Screw, 8-32 x 1 Phillips-head, stainless steel (for magnetic switch)
• 30145 Screw, 6-32 x
1
/2 Phillips-head, stainless steel (secures battery cover plate
to battery posts)
• 30242 Washer, #6 flat, stainless steel (for 30145)
• 30414 Washer, #12, internal tooth (secures battery bulkhead retainer)
• 30954 Screw 4-40 x 3/16 Phillips-head, stainless steel (securing screw for PCB
retainer rod)
• 31119 Screw 6-32 x 5/8 Truss Head (secures battery bulkhead retainer to
bulkhead bottom plate)
• 30176 Screw, 10-24 x 3/4, Phillips-head, stainless steel (secures Celcon threaded
ring inside titanium battery end cap)
• 30249 Washer #10, Flat, stainless steel (used with 30176)
• 30447 Bolt, ¼-20 x 1 ¼ Hex, titanium (secures lift eye to battery end cap)
• 31089 Screw, 10-32 x
1
/2 flat Phillips-head, titanium (secures sensor end cap to
housing - side opposite conductivity cell guard)
• 31090 Screw, 10-32 x
5
/8 flat Phillips-head, titanium (secures conductivity cell
guard to housing)
• 31118 Screw, 10-32 x 3/8 Phillips-head, titanium (secures conductivity cell guard
to sensor end cap)
• 30875 Bolt ¼-20 x 5/8 Hex, titanium (secures connector guard to sensor end cap)
• 30633 Washer, ¼” split ring lock, titanium (for 30875)
• 30919 Screw, 6-32 x 3/8 flat slotted, titanium (secures anti-foulant device cup to
conductivity cell guard)
• 31066 Screw, 8-32 x ¾ socket, titanium (secures conductivity cell and TC duct to
sensor end cap)
• 31225 Bolt, ¼-20 x 1¼ Hex, titanium (mount 19plus V2 to cage)
• 31138 Bolt, ¼-20 x 3/4 Hex, stainless steel (mount cross bars to cage)
-
50434
Seaspares kit,
standard connectors
Includes o-rings, hardware, bulkhead connectors, dummy plugs, etc.:
• 50087 Conductivity cell filling and storage kit
• 50273 Spare hardware kit (see above)
• 50274 Spare o-ring kit (see above)
• 50275 Spare magnetic switch assembly
• 41124 Battery cover plate
• 801225 Data I/O cable, 4-pin RMG-4FS to 9-pin DB -9S cable, 2.4 m (8 ft) long
• 171888 Cable adapter, DB-25 to DB-9
• 17046.1 4-pin RMG-4FS dummy plug with locking sleeve
• 17047.1 6-pin AG-206 dummy plug with locking sleeve
• 17654 4-pin XSG-4-BCL-HP-SS bulkhead connector
• 17628 6-pin AG-306-HP-SS bulkhead connector
• 30388 Vinyl tube, ¾” x ½” (main sensor plumbing tubing)
• 30409 Teflon tape (for insides of hose clamps)
• 30411 Triton X100 (for cell cleaning)
• 30457 Parker O-Lube (o-ring lubricant)
-
continued on next page
