Appendix V: Replacement Parts
111
Appendix V: Replacement Parts
Part
Number
Part Application Description
Quantity
in 19plus
V2
22018
Alkaline D-cell batteries,
Duracell MN 1300 (LR20)
Power 19plus V2 9
41124B Battery cover plate Retains alkaline batteries 1
801511
NiMH battery pack
Optional rechargeable 9-cell battery pack -
90504
NiMH battery pack charger
For NiMH batteries -
801641 Ni-Cad battery pack Optional rechargeable 9-cell battery pack -
90226 Ni-Cad battery charger For Ni-Cad batteries -
30411 Triton X-100
Octyl Phenol Ethoxylate – Reagent grade non-ionic cleaning solution
for conductivity cell (supplied in 100% strength; dilute as directed)
1
50288 Moored Mode Conversion Kit
Anti-foulant device fittings for moored applications (order AF24173
Anti-Foulant Devices separately)
-
801542 AF24173 Anti-Foulant Device
bis(tributyltin) oxide device inserted into anti-foulant device cup, for
moored applications
1 (set of 2)
17709*
6-pin AG-206 to 2-pin RMG-2FS and
4-pin RMG-4MP Pump / Data I/O-
Power Y-cable
From SBE 19plus V2 bulkhead connector to pump (2-pin) and data
I/O - power (4-pin)
1
801225*
4-pin RMG-4FS to 9-pin DB-9S I/O
cable, 2.4 m (8 ft)
From 4-pin connector on Y-cable 17709 to computer 1
171888
25-pin DB-25S to 9-pin DB-9P
cable adapter
For use with computer with DB-25 connector
1
17080*
2-pin RMG-2FS to 2-pin RMG-2FS
cable, 0.4 m (1.2 ft)
From 2-pin connector on Y-cable 17709 to pump 1
17044.1*
2-pin RMG-2FS dummy plug with
locking sleeve
For 2-pin connector on Y-cable 17709, when pump not used 1
17046.1*
4-pin RMG-4FS dummy plug with
locking sleeve
For 4-pin connector on Y-cable 17709, when I/O cable not used.
Also, for 4-pin RS-232 auxiliary sensor connector when not used.
2
17047.1 *
6-pin AG-206 dummy plug with
locking sleeve
For when auxiliary differential input sensors not used 3
171883
6-pin MCIL-6FS to 2-pin MCIL-2FS
and 4-pin MCIL-4MP Pump / Data I/O
Y-cable
From SBE 19plus V2 bulkhead connector to pump (2-pin) and data
I/O - power (4-pin)
1
801374
4-pin MCIL-4FS (wet-pluggable) to
9-pin DB-9S I/O cable, 2.4 m (8 ft)
From 4-pin connector on Y-cable 171883 to computer 1
171502
2-pin MCIL-2FS to 2-pin MCIL-2FS
(wet-pluggable) cable, 0.4 m (1.2 ft)
From 2-pin connector on Y-cable 171883 to pump 1
171497.1
2-pin MCDC-2-F wet-pluggable dummy
plug with locking sleeve
For 2-pin connector on Y-cable 171883 when pump not used 1
171398.1
4-pin MCDC-4-F wet-pluggable dummy
plug with locking sleeve
For 4-pin connector on Y-cable 171883 when I/O cable not used.
Also, for 4-pin RS-232 auxiliary sensor connector when not used.
2
171498.1
6-pin MCDC-6-F wet-pluggable dummy
plug with locking sleeve
For when auxiliary differential input sensors not used 3
50275 Spare magnetic switch assembly For starting/stopping logging in Profiling mode -
90087 Pump air bleed valve assembly Y fitting, air bleed valve, cable ties, vinyl tubing 1
30388 Tygon tube, ½ inch ID x ¾ inch OD Main plumbing tubing -
30579 Tygon tube, 3/8 inch ID x ½ inch OD
13 mm (0.5 inch) long pieces used on conductivity cell exhaust cap
used with optional Anti-Foulant Devices and for SBE 43 intake and
exhaust to fit to main plumbing
-
22009 Panasonic BR-2/3A lithium batteries Back-up lithium cells on Power PCB 3
* For standard bulkhead connectors continued on next page
