Sea-Bird Electronics SBE 19plusV2 - Calibrations

Appendix III: Command Summary
106
CATEGORY COMMAND
DESCRIPTION
TCalDate=S
S=Temperature calibration date.
TAO=F
F=Temperature A0.
TA1=F
F=Temperature A1.
TA2=F
F=Temperature A2.
TA3=F
F=Temperature A3.
TOffset=F
F=Temperature offset correction.
CCalDate=S
S=Conductivity calibration date.
CG=F
F=Conductivity G.
CH=F
F=Conductivity H.
CI=F
F=Conductivity I.
CJ=F
F=Conductivity J.
CPCor=F
F=Conductivity pcor.
CTCor=F
F=Conductivity tcor.
CSlope=F
F=Conductivity slope correction.
PCalDate=S
S=Pressure calibration date.
PRange=F
F=Pressure sensor full scale range (psia).
POffset=F
F=Pressure offset correction.
PA0=F
F=Strain-gauge pressure A0.
PA1=F
F=Strain-gauge pressure A1.
PA2=F
F=Strain-gauge pressure A2.
PTempA0=F
F=Strain-gauge pressure temperature A0.
PTempA1=F
F=Strain-gauge pressure temperature A1.
PTempA2=F
F=Strain-gauge pressure temperature A2.
PTCA0=F
F=Strain-gauge pressure temperature compensation ptca0.
PTCA1=F
F=Strain-gauge pressure temperature compensation ptca1.
PTCA2=F
F=Strain-gauge pressure temperature compensation ptca2.
PTCB0=F
F=Strain-gauge pressure temperature compensation ptcb0.
PTCB1=F
F=Strain-gauge pressure temperature compensation ptcb1.
PTCB2=F
F=Strain-gauge pressure temperature compensation ptcb2.
PC1=F
F=Quartz pressure C1.
PC2=F
F=Quartz pressure C2.
PC3=F
F=Quartz pressure C3.
PD1=F
F=Quartz pressure D1.
PD2=F
F=Quartz pressure D2.
PT1=F
F=Quartz pressure T1.
PT2=F
F=Quartz pressure T2.
PT3=F
F=Quartz pressure T3.
PT4=F
F=Quartz pressure T4.
PSlope=F
F=Quartz pressure slope correction.
ExtFreqSF=F
F=External frequency (Quartz pressure sensor) scale factor.
Calibration
Coefficients
(F=floating
point number;
S=string with
no spaces)
Dates shown
are when
calibrations
were
performed.
Calibration
coefficients
are initially
factory-set and
should agree
with
Calibration
Certificates
shipped with
19plus V2.
View all
coefficients
with GetCC
or DCal.
VOffset0=,
VSlope0=,
. . .
VSlope5=,
VOffset5=
Voltage channel offsets and slopes are all factory set, and
should never be modified by customer. These are properties of
19plus V2 electronics, and are not calibration coefficients for
auxiliary sensors. Enter calibration coefficients for auxiliary
sensors in .con file in SEASAVE and/or SBE Data Processing.
Hardware
Configuration
Factory Settings – do not modify in the field
SetMfgDate=
SetPcbSerialNum1=, SetPcbSerialNum2=,
SetPcbSerialNum3=, SetPcbSerialNum4=
SetPcbAssembly1=, SetPcbAssembly2=,
SetPcbAssembly3=, SetPcbAssembly4=
Auxiliary Sensor Settings – can be modified in the field to accommodate changes in
auxiliary sensors cabled to 19plus V2
SetVoltType0=, SetVoltSN0=
SetVoltType1=, SetVoltSN1=
SetVoltType2=, SetVoltSN2=
SetVoltType3=, SetVoltSN3=
SetVoltType4=, SetVoltSN4=
SetVoltType5=, SetVoltSN5=
