F22E03Y
2
1
1. Pinch engine cylinder drain hose
2. Pinch engine heat exchanger drain hose
Install hose pinchers and disconnect
hoses at the following location:
Remove engine cover to gain access
to the engine. Lock steering pole in
upright position with the holder.
WARNING
Always install steering pole holder
immediately after engine cover re-
moval to securely support the pole
while working in the engine com-
partment.
F22E04Y
2
1
3
1. Disconnect water supply hose
2. Pinch outlet hose
3. Install a temporary hose here
Make sure the hose is properly con-
nected to the magneto cover.
F22E02Y
1
1. Hose properly connected
Insert a funnel into the temporary hose
and pour in 1.3 L (1.4 U.S. qt) of undi-
luted antifreeze (100% concentration)
until water/antifreeze mix flows out of
the cooling system bleed outlet. Use
a container to collect water flowing.
1
F22L0HZ
COOLING SYSTEM BLEED OUTLET
1. Water/antifreeze mix will flow out
from this hole
Place a container at rear of watercraft
to collect the water/antifreeze mix.
88
