MAINTENANCE PROCEDURES
sbs2009-011-001_a
1. Apply product here
3. Pull rubber seal back on its seat
making sure the tabs on the ignition
coil and the slots in the seal properly
match together.
4. Leave a ring of grease on top of the
seal as shown to act as a water bar-
rier. Wipe off the excess.
sbs2009-011-003_a
1. Correctly shaped excess of product
5.Pushtheignitioncoildowntose-
curely install it on the spark plug tip.
NOTE: Ensure the seal seats properly
with the top surface of the engine.
NOTE: Ensure the seal seats properly
with the engine top surface.
6. Reconnect ignition coil connectors.
7. To reinstall engine cover, pu
sh it
downward until it snaps.
8. Wipe up any residual water f
rom the
engine.
9. Disconnect the garden
hose.
NOTE: It is recommended to fog the
engine valves with XPS
Lube. Contact
your authorized Sea-Doo dealer.
Exhaust System Flushing
Flushing the exhaust system and in-
tercooler (supercharged models) with
fresh water is essential to neutralize
corroding effects of salt or other chem-
ical products present in water. It will
help to remove sand, salt, shells or
other particles in water jackets and/or
hoses.
Flushing should be performed when
the watercraft is not expected to be
used further the same day or when the
watercraft is stored for any extended
time.
WARNING
Perform this operation in a well
ventilated area.
Proceed as follows:
Clean jet pump by spraying water in its
inletand outletand then applya coating
of XPS Lube or equivalent.
CAUTION When operating the
engine while the watercraft is out
of the water, the heat exchanger in
therideplatemaybecomeveryhot.
Avoid any contact with ride plate as
burns may occur.
Connect a garden hose to connector
located at the rear of watercraft on jet
pump support. Do not open water tap
yet.
NOTE: An optional quick connect
adapter can be used (P/N 295 500 473).
No hose pincher is required to flush en-
gine.
72
