CONTROLS/INSTRUMENTS/EQUIPMENTS
F00L2TY
12
1. Latch hole
2. Pin
Engine Compartment
Removing the seat provides access to
the engine, electrical and fuel systems.
WARNING
Certain components in the engine
compartment may be very hot.
Direct contact may result in skin
burn. When starting or operating
the engine, do not touch any elec-
trical part. Never leave any object,
rag, tool, etc., in the engine com-
partment or in the bilge.
11) Passenger Handholds
The seat strap provides a handhold for
a passenger to hold on to when riding.
The sides of the molded grab handle at
the rear of the seat also provide a hand-
hold for a passenger. The rear portion
of the molded grab handle provides a
handhold for the skier/wakeboarder
spotter, or for boarding the watercraft
from the water.
NOTICE
Never use the molded
grab handle to tow anything or to lift
the watercraft.
smo2010-001-005 _a
TYPICAL - PASSENGER HANDHOLDS
1. Seat strap
2. Molded grab handle
12) Front and Rear
(bow/stern) Eyelets
Eyelets can be used for mooring, tow-
ing and as a tie-down points when trai-
lering your watercraft.
Front (bow) Eyelet
smo2008-001-019_a
GTS PRO MODEL
1. Eyelet
46
