CONTROLS/INSTRUMENTS/EQUIPMENTS
smo2008-001-020_a
RXP-X 255 MODEL
1. Eyelet
Rear (stern) Eyelet
smo2008-001-016_a
TYPICAL - RXP-X 255 MODEL
1. Eyelet
smo2008-001-017_a
TYPICAL - GTS PRO MODEL
1. Eyelet
NOTE: The eyelet used on your model
watercraft may not come with the
hook in the center of the eyel
et.
smo2008-001-018_a
RXP-X 255 MODEL
1. Eyelets
13) Mooring Cleats
These cleats can be temporarily used
for docking, while refueling for exam-
ple.
F18L0SY
1
TYPICAL — GTS PRO MODEL
1. Mooring cleats
NOTICE
Never use mooring cleats
to pull or lift the watercraft.
14) Bilge Drain Plugs
Unscrew drain plugs whenever wa-
tercraft is on the trailer. This will allow
water accumulated in the bilge to be
evacuated and helps to reduce con-
densation.
NOTICE
Remove watercraft from
water prior to unscrewing drain
plugs.
_______________
47
