SPECIFICATIONS
WATERCRAFT RXP-X 255
ENGINE
Rotax
®
1503 4-TEC
®
.
Single Over Head Camshaft (SOHC)
Type
173 kW
Number of cylinders 3
Number of valves
12 valves (4 per cylinder) with
hydraulic lifters (no adjustment)
Displacement 1 494 cm³ (91.2 in³)
Type
Supercharged with intercooler
Intake system
Throttle body 52 mm (2 in)
Bore 100 mm (3.9 in)
Stroke
63.4 mm (2.5 in)
Compression ratio
8.4:1
Cooling Closed-loop system
ELECTRICAL SYSTEM
Ignition Digital inductive
Starter
Electric
Battery 12 V, 30 A•h. Electrolyte type
Make and type
NGK, DCPR8E
Spark plug
Gap
0.75 mm (.03 in)
PROPULSION
Propulsion system
Sea-Doo
®
direct drive
Type
Axial flow, single stage. Large
hub with 10-vane stator
Jet pump
Material Aluminum
Impeller
Stainless steel
Transmission Type Direct drive, forward/neutral/reverse
VTS
Type Electric
86
