CONTROLS/INSTRUMENTS/EQUIPMENTS
Storage Bin Installation
Insert storage bin front tabs under-
neath storage cover shock support.
Push on storage bin to secure in place
with locking device.
smo2008-001-069_b
Step 1: Insert storage bin front tabs
Step 2: Push to secure
NOTICE
Never operate the water-
craft without the storage bin prop-
erly installed or water might enter
and fill the bilge.
Fire Extinguisher Holder
NOTE: Fire extinguisher is sold sepa-
rately.
GTS Pro Models
Use support inside removable stor-
age bin in front storage compartment
and secure extinguisher using rubber
latches.
smo2007-002-008_a
RXP-X 255 Model
Liftthestoragebintoobtainaccessto
theholderforanapprovedfireextin-
guisher (sold separately). It also con-
tains the Operator’s Guide.
F19L0BY
10) Seat Latch
Removing the seat allows access to
the engine compartment.
The seat latch is located at the rear of,
and underneath the seat.
smo2008-001-015_a
TYPICAL
1. Seat latch
To remove seat, pull the latch lever up-
ward and hold. Lift and pull the seat
rearward.
To latch seat, align latch hole with pin
then, firmly push down on the rea
r por-
tion of the seat.
