SECOP 105N4866 - Page 17

XT Controllers for NLV-CN Compressors
Page 32 / 33
Parameter Function Code Min. Max.
Default
Setting
Unit
Number of compressors g01 1 3 1 -
Compressor minimum stop time g03 1 240 90 sec
Compressor minimum run time g04 1 240 30 sec
Compressor period time g05 5 30 15 min
Compressor swap time
0 = None
g06 0 60 1 day
Compressor capacity for starting PWM control g07 1 100 1 %
Compressor capacity for starting speed control g08 20 100 45 %
CC Control Mode
0 = Internal temperature control (PID)
1 = External analog signal (AIO1)
2 = External analog signal (AIO2)
g09 0 2 0 -
Capacity compressor 1 g10 0 100 RO %
Capacity compressor 2 g11 0 100 RO %
Capacity compressor 3 g12 0 100 RO %
Actual main compressor/swapped g13 0 3 RO -
Compressor start delay g14 0 60 5 sec
Parameter Function Code Min. Max.
Default
Setting
Unit
Electronic power up delay n24 0 240 9 sec
Sensor failure capacity n21 0 100 60 %
Compressor capacity switching on door open
(n23)
0 = Off
1 = On
n22 0/no 1/yes 1 -
Capacity at door open n23 0 100 50 %
Capacity override select:
0 = Temperature Control
1 = Pause Temperature Control (external)
2 = Stop Temperature Control (external)
n28 0 2 RO -
Capacity override value (if n28=1) n29 0 100 RO %
Parameter Function Code Min. Max.
Default
Setting
Unit
Smart Set:
0 : User defined
1 : Very slow control
2 : Slow control
3 : Medium control (default)
4 : Fast control
5 : Very fast control
n30 0 5 3 -
PID polynomial R1 n35 -50 50.0 -1 -
PID polynomial R2 n36 -50 50.0 0 -
PID polynomial S0 n37 -50 50.0 -4 -
PID polynomial S1 n38 -50 50.0 3,9 -
PID polynomial S2 n39 -50 50.0 0 -
PID polynomial T0 n40 -50 50.0 -4 -
PID polynomial T1 n41 -50 50.0 3,9 -
PID polynomial T2 n42 -50 50.0 0 -
h sampling time n43 10 600 30 sec.
U
min
minimum saturation value (high word) n44 0 100 0 -
U
max
maximum saturation value (high word) n45 0 100 100 -
T
act
below
T
ref
to start pull up limit
n46 -10 0 -3 K
T
act
above
T
ref
to start pull down limit
n47 0 10 3 K
T
act
below
T
ref
to end pull down limit
n48 -10 10 0 K
T
act
above
T
ref
to end pull up limit
n49 -10 10 0 K
Temperature out of range timeout n50 0.0 30.0 4 min.
Optimized pull down time n51 0.0 30.0 10 min.
Optimized pull down capacity n52 20 100 60 %
Default capacity day n53 0 100 60 %
Default capacity night n54 0 100 55 %
Out requested capacity (RO) n55 0 100 RO %
Controller state:
0=Off,
1=Pull down
2=Pull up
3=In range
4=Out of range Up
5=Out of range down
6=Override
n56 0 6 RO -
