XT Controllers for NLV-CN Compressors
Page 76 / 77
8.5.
Capacity and
Performance
Data NLV10CN
LBP: ASHRAE 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 352 395 439 477 514 593 671 749 Evaporation pressure -23.3°C -10°F
Capacity [BTU/h] 1202 1350 1498 1627 1756 2024 2291 2559 Condensing pressure 54.4°C 130°F
Power cons. [W] 203 223 243 266 289 334 380 425 Liquid temperature 32.2°C 90°F
Current cons. [A] 1.08 1.16 1.24 1.35 1.45 1.71 1.96 2.21 Return gas temp. 32.2°C 90°F
COP [W/W] 1.74 1.78 1.81 1.79 1.78 1.77 1.77 1.76
EER [BTU/Wh] 5.93 6.06 6.18 6.12 6.07 6.05 6.03 6.02
LBP: CECOMAF 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 264 296 329 357 385 444 502 561 Evaporation pressure -25°C -13°F
Capacity [BTU/h] 900 1012 1124 1220 1315 1515 1715 1914 Condensing pressure 55°C 131°F
Power cons. [W] 195 214 234 256 278 321 365 408 Liquid temperature 55°C 131°F
Current cons. [A] 1.03 1.11 1.19 1.29 1.39 1.63 1.87 2.11 Return gas temp. 32°C 90°F
COP [W/W] 1.35 1.38 1.41 1.40 1.39 1.38 1.38 1.37
EER [BTU/Wh] 4.61 4.72 4.81 4.77 4.74 4.72 4.7 4.69
LBP: EN12900 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 195 220 245 269 293 333 373 412 Evaporation pressure -35°C -31°F
Capacity [BTU/h] 665 752 838 920 1002 1137 1273 1408 Condensing pressure 40°C 104°F
Power cons. [W] 137 154 171 186 201 234 267 299 Liquid temperature 40°C 104°F
Current cons. [A] 0.62 0.75 0.87 0.96 1.04 1.18 1.31 1.44 Return gas temp. 20°C 68°F
COP [W/W] 1.42 1.43 1.44 1.45 1.46 1.42 1.40 1.38
EER [BTU/Wh] 4.85 4.88 4.91 4.95 4.98 4.86 4.78 4.71
MBP: ASHRAE 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 636 708 781 855 929 1072 1215 1357 Evaporation pressure -6.7°C 20°F
Capacity [BTU/h] 2172 2419 2665 2919 3173 3661 4148 4635 Condensing pressure 54.4°C 130°F
Power cons. [W] 289 315 341 374 408 476 544 612 Liquid temperature 46.1°C 115°F
Current cons. [A] 1.51 1.66 1.81 1.95 2.08 2.47 2.86 3.25 Return gas temp. 35°C 95°F
COP [W/W] 2.21 2.25 2.29 2.28 2.28 2.25 2.23 2.22
EER [BTU/Wh] 7.53 7.68 7.81 7.8 7.79 7.69 7.63 7.57
MBP: CECOMAF 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 505 563 621 679 737 850 964 1077 Evaporation pressure -10°C 14°F
Capacity [BTU/h] 1725 1923 2121 2318 2515 2903 3291 3680 Condensing pressure 55°C 131°F
Power cons. [W] 275 300 324 356 387 450 513 577 Liquid temperature 55°C 131°F
Current cons. [A] 1.44 1.58 1.71 1.84 1.97 2.34 2.70 3.06 Return gas temp. 32°C 90°F
COP [W/W] 1.84 1.88 1.92 1.91 1.90 1.89 1.88 1.87
EER [BTU/Wh] 6.28 6.42 6.54 6.52 6.50 6.45 6.41 6.38
MBP: EN12900 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 555 621 688 756 824 945 1067 1188 Evaporation pressure -10°C 14°F
Capacity [BTU/h] 1894 2121 2348 2581 2813 3228 3642 4057 Condensing pressure 45°C 113°F
Power cons. [W] 242 269 295 325 355 417 479 541 Liquid temperature 45°C 113°F
Current cons. [A] 1.25 1.41 1.56 1.70 1.84 2.15 2.47 2.78 Return gas temp. 20°C 90°F
COP [W/W] 2.29 2.31 2.33 2.33 2.32 2.27 2.23 2.20
EER [BTU/Wh] 7.83 7.90 7.95 7.94 7.93 7.75 7.61 7.50
8.6.
Capacity and
Performance
Data NLV8.0CN
LBP: ASHRAE 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 266 306 346 365 384 442 500 558 Evaporation pressure -23.3°C -10°F
Capacity [BTU/h] 907 1044 1182 1247 1313 1510 1708 1905 Condensing pressure 54.4°C 130°F
Power cons. [W] 153 171 188 202 217 252 288 324 Liquid temperature 32.2°C 90°F
Current cons. [A] 0.70 0.82 0.94 0.98 1.03 1.26 1.49 1.72 Return gas temp. 32.2°C 90°F
COP [W/W] 1.73 1.79 1.84 1.81 1.78 1.75 1.74 1.72
EER [BTU/Wh] 5.91 6.11 6.28 6.16 6.06 5.98 5.92 5.88
LBP: CECOMAF 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 198 229 260 273 286 329 372 415 Evaporation pressure -25°C -13°F
Capacity [BTU/h] 677 782 887 931 975 1122 1269 1416 Condensing pressure 55°C 131°F
Power cons. [W] 148 165 181 195 208 242 277 311 Liquid temperature 55°C 131°F
Current cons. [A] 0.66 0.78 0.90 0.94 0.98 1.20 1.43 1.65 Return gas temp. 32°C 90°F
COP [W/W] 1.34 1.39 1.43 1.40 1.38 1.36 1.34 1.33
EER [BTU/Wh] 4.59 4.75 4.89 4.79 4.70 4.63 4.59 4.55
LBP: EN12900 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 148 171 194 207 220 252 284 316 Evaporation pressure -35°C -31°F
Capacity [BTU/h] 505 583 661 706 750 860 970 1080 Condensing pressure 40°C 104°F
Power cons. [W] 104 120 135 144 154 178 202 226 Liquid temperature 40°C 104°F
Current cons. [A] 0.45 0.52 0.58 0.67 0.75 0.82 0.89 0.96 Return gas temp. 20°C 68°F
COP [W/W] 1.42 1.43 1.44 1.43 1.43 1.42 1.41 1.40
EER [BTU/Wh] 4.85 4.88 4.90 4.89 4.88 4.84 4.81 4.78
MBP: ASHRAE 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 489 553 616 667 718 828 939 1049 Evaporation pressure -6.7°C 20°F
Capacity [BTU/h] 1671 1887 2103 2278 2453 2829 3205 3581 Condensing pressure 54.4°C 130°F
Power cons. [W] 216 239 262 284 306 357 407 458 Liquid temperature 46.1°C 115°F
Current cons. [A] 1.09 1.22 1.35 1.46 1.56 1.85 2.13 2.41 Return gas temp. 35°C 95°F
COP [W/W] 2.27 2.31 2.35 2.35 2.35 2.32 2.31 2.29
EER [BTU/Wh] 7.74 7.89 8.02 8.02 8.02 7.93 7.87 7.82
MBP: CECOMAF 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 387 439 490 528 567 654 740 827 Evaporation pressure -10°C 14°F
Capacity [BTU/h] 1322 1498 1673 1805 1936 2232 2528 2824 Condensing pressure 55°C 131°F
Power cons. [W] 206 228 249 270 291 338 386 434 Liquid temperature 55°C 131°F
Current cons. [A] 1.03 1.15 1.27 1.37 1.47 1.74 2.01 2.27 Return gas temp. 32°C 90°F
COP [W/W] 1.88 1.93 1.96 1.96 1.95 1.93 1.92 1.91
EER [BTU/Wh] 6.42 6.58 6.71 6.68 6.66 6.60 6.55 6.51
MBP: EN12900 115/220 V, 50/60 Hz, fan cooling F
2
Speed (rpm) 2000 2250 2500 2750 3000 3500 4000 4500
Test conditions
Capacity [W] 431 487 542 592 641 741 841 941 Evaporation pressure -10°C 14°F
Capacity [BTU/h] 1472 1662 1852 2021 2189 2530 2871 3212 Condensing pressure 45°C 113°F
Power cons. [W] 184 206 227 248 269 316 363 411 Liquid temperature 45°C 113°F
Current cons. [A] 0.92 1.02 1.12 1.25 1.38 1.62 1.87 2.11 Return gas temp. 20°C 90°F
COP [W/W] 2.35 2.37 2.39 2.38 2.38 2.34 2.31 2.29
EER [BTU/Wh] 8.01 8.08 8.14 8.14 8.14 8.00 7.90 7.82
