Secure Care KinderGUARD ID - Page 49

Doc. No.: A05280692 Rev. AE ECO: 13200 Date: 11/04/2019
49
In order for the Cutband Receiver to change its address set by the dipswitch, the Cutband Receiver needs to be powered
down and then powered back up.
SECTION 9 INSTALLATION AND CONNECTIONS
ON
1 2 3 4 5 6 7 8
Address = 90
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
ON
1 2 3 4 5 6 7 8
Address = 91
Address = 92
Address = 93
Address = 94
Address = 95
