If you have purchased a 983 Ext. Receiver Kit, please connect the Ext. Receiver as shown below. DO NOT
CONNECT the filter in the cover of the Receiver. The filter is only used for the Legacy ID system
applications. For this application connect the 6 pin connector directly to the Antenna/Receiver RJ-11 Jack.
APPENDIX C 983 EXT. RECEIVER KIT
ID, 135DE, AND 135 Ext. Receiver Connection
