Secure Care KinderGUARD ID - Page 5

Doc. No.: A05280692 Rev. AE ECO: 13200 Date: 11/04/2019
5
Using a Transmitter/System Tester 64
SECTION 12 TROUBLESHOOTING 65
SECTION 13 GENERAL PRODUCT WARRANTY 69
1. Notices 69
2. Limited Warranty 71
3. Limitations of Liability 72
4. Governing Law and Arbitration 72
5. Severability 73
6. Waiver 73
SECTION 14 COMPLIANCE INFORMATION 73
APPENDIX A UL LISTING REQUIREMENTS 82
APPENDIX B FERRITE PLACEMENT 83
Recommended Ferrite Placement 83
Correct and Incorrect Ferrite Installation 84
APPENDIX C 983 EXT. RECEIVER KIT 85
Cutband Receiver Layout 86
APPENDIX D OLD CUTBAND RECEIVER LAYOUT AND DIPSWITCH SETTINGS 86
Cutband Receiver to XIU Connections 87
Setting the Proper Cutband Receiver ID Code 88
APPENDIX E OLD PM PROGRAMMING 93
PM Mode Feature 93
Display PM Times 93
APPENDIX F 4 AMP POWER SUPPLY FOR EXIT PANELS 94
APPENDIX G 4 AMP POWER SUPPLY FOR CUTBANDS 95
Power Supply Connections for the Cutband Receiver 95
