10
In the Operating Mode the screens will show
as follows:
Please note: The heater icon will show if
the heater is disabled and also if the heater
is enabled but not operating.
If the heater is enabled and the minimum
temperature is greater than the ceiling
temperature screen two in Operational Mode
would show:
Note:
The heater icon flashes on ( ) then off (
) whilst the heater is ON. The fan speed
automatically adjusts to medium (2) speed
to ensure sufficient air passes over the
heater element. The fan speed can not be
adjusted in Heater Mode. The fan speed
can be changed in Setup Mode but this
change will not take effect until the ceiling
temperature rises above the minimum
temperature setting.
Heater Mode
Once the heater is enabled this additional
menu option is available. Heater Mode
allows the householder to choose between
the three heater mode settings.
• Normal Mode, where the heater is turned
ON and OFF depending on the ceiling
temperature in relation to the minimum
temperature.
Normal
Operation
Ceiling Vent
Heat Fan2x
Ceiling Vent
Heat Fan3x
• Override Mode, where the householder
can force the heater ON for a certain time
period irrespective of the ceiling
temperature and minimum temperature
setting.
• Timer Mode, where one or two time
periods can be set by the householder
to control the time the heater comes on,
when the ceiling temperature is below
the minimum temperature setting.
Note: To operate in the Override and
Timer modes the real time clock must be
set properly, because these are time relative
operating modes. Refer to the Set Real
Time Clock section.
Override Heater Mode
This mode operates independently of the
temperature in the ceiling. The householder
can enter this mode if the heater is enabled
and choose the heater to turn on for either
1, 2, 4, or 6 hours from the time selected.
The heater will stay on for this period then
turn off and Normal Mode will continue.
(Press x6)
SELECT
MODE
Heater
Mode
Heater Mode:
Normal
