16
Note:
1) In a power cut situation an on-board
battery keeps the clock operational
2) The setting of the clock is done in 24hr
format but for readability the clock that
is displayed on screen two of Operational
Mode is a 12 hour format (am/pm)
3) If for some reason such as touching
the circuitry during installation the clock
is ‘upset’ then the display flashes:
This can be fixed by resetting the clock as
described above.
4) If a heater is installed, enabled and in
Timer or Override mode then a clock
error disables the heater and these
modes which rely on the clock are not
functional until the clock is reset.
Clock Error
Fan Mode
Note: Only applies to Eco Smart-Vent
models (SV01, SV02, SV04 & SV06).
Does not apply to Summer-Vent models
(SV02S, SV04S & SV06S).
Use this function if you would like your
system to turn off once your ceiling
temperature exceeds the maximum
temperature.
Fan Mode controls the operation of the fan
when the ceiling temperature exceeds the
system maximum temperature threshold.
This feature is enabled when the user does
not want the system to operate when the
air in the ceiling space exceeds 35
o
C for
example.
Default operation for Fan Mode is the fan
operating at low (1) speed above maximum
temperature.
The Reset button defaults to FAN Mode
Normal.
To disable the fan above maximum
temperature:
To access the Fan Mode press:
(Press x 1)
SELECT
Fan
Mode
MODE
