Secutron Inc. 13
2 Preparing to Install the
MR-2605 Fire Panel
2.1 Unpacking the MR-2605
The basic MR-2605 package includes the following components:
• Cabinet with hinged door
• Display and control plate c/w display and control printed circuit board.
• Zone label insert
• Battery compartment dead front plate
• Main control PCB
•Transformer
• Installation manual
• Hardware pack
• 2 × NAC EOL resistors (4.7 K, 5%, ½ W)
• 5 × Zone EOL resistors (4.7 K, 5%, ½ W)
• 1 × Battery jumper wire
• 1 × EGND terminal ring
• 1 × EGND KEP nut
• Door keys (taped to outside of cabinet)
All components described above are factory assembled into the enclosure.
