5.8 Walk Test (Installer function only)
To do a walk test, all zone alarms, troubles and relays must be in their normal state. You can
program the walk test to be either audible or silent (see 6.3.4 Signal Silence Inhibit Timer and
Walk Test Programming on page 46).
1. To walk test the panel press the Walk Test button. The common trouble LED flashes and the
buzzer sounds one short beep. The panel will be in walk test mode for one hour, or until you
press the Walk Test button again.
2. As you test each part of the system, the panel will give the following indications:
Zone LEDs operate normally except that alarms do not latch - the alarm LEDs will turn off
when the zone is restored and the auto-reset has been successful.
Alarm and trouble relays are NOT activated. If used, any remote connection is not activated.
3. To return the system to normal operation, press the Walk Test button. If you do not press the
Walk Test button, the system will return to normal operation after one hour. If any zones are
in alarm at the end of the walk test, the zones will indicate silenced signals.
Type of activation LEDs NACs* Trouble Buzzer
Fire Alarm or Fire Supervisory Zone alarm/Supv LED turns on 1 squawk
Fire Alarm or Fire Supervisory
Restoral
Zone alarm/Supv LED turns off 1 squawk
Zone or System Trouble Zone or system trouble LED turns on 2 squawks Sounds
Zone or System Trouble Restoral Zone or system trouble LED turns off 2 squawks Stops sounding
Ground Fault Ground trouble LED turns on 3 squawks Sounds
Ground Fault Restoral Ground trouble LED turns off 3 squawks Stops sounding
Note: *Only if Walk Test Audible option is turned on.
Note: The Lamp Test button does not work while the panel is in Walk Test mode.Walk Test function not
available without AC power.
