ASSEMBLY AND INSTALLATION
6
4
Fit and secure the Coin Chute Tower to the Left Hand Coin Chute Tower Spacer and secure using 4x M8
Hex Nuts (supplied).
5
Repeat steps 2 and 3 to apply the Coin Tower Holders (PD-1214UK) and Coin Tower Spacer Right (RD-
0052UK) to the Right Hand Cabinet.
Coin Tower Spacer Right.
(PD-0052UK)
M8 Hex Nut (4)
Coin Chute Tower (RD-0300UK)
