Print Server Status Information
Print Server User Manual Windows 62
Viewing the Status Information via the InterCon-NetTool
Requirements
 The InterCon-NetTool is installed on the client, see: 15.
Proceed as follows:
1. Start the InterCon-NetTool.
2. Double-click the print server in the device list.
The Properties dialog appears.
3. Select the desired menu item from the navigation bar in the
Status category.
 The status information is shown.
7.2 What Status Information is Shown?
This chapter gives an overview of the print server status informa-
tion. Different status information is available depending on your
print server model.
General Status
The General page shows status information, such as the name of the
print server, the hardware address, and the serial and version num-
bers, network type etc. The text which you previously entered under
'Configuration - General' will now appear under 'Description.' A
description is freely definable and can be used to gain a better over-
view of the print servers and printers in the system.
WLAN Status
The WLAN page contains information about the current WLAN set-
tings.
• 'Connection Status' indicates the status of the network
connection.
- 'Ad hoc': The print server is in ad hoc mode.
- 'Infrastructure': The print server is in infrastructure mode.
- 'Out of Range': The print server is logged onto an access point in the
infrastructure mode and this access point cannot be reached because it has
been turned off, for example.
- 'Searching': The print server is searching for an access point.
• 'Current network name' indicates the name (SSID - Service Set
Identifier) of the WLAN.
• 'Speed' indicates the data transfer rate.
• 'Level' indicates the strength of the signal.
