Printing in Windows
Printserver User Manual Windows 11
4. From the shortcut menu, select Printer properties.
The Properties dialog appears.
5. Select the Ports tab.
6. In the list, select the port.
7. Click Configure.
The Configure Standard TCP/IP Port Monitor dialog appears.
8. In the Protocol area, tick the option Raw.
9. In the Raw Settings area, define the Port Number.
10. Untick SNMP Status Enabled.
11. Click OK to confirm.
 The settings will be saved.
2.2 How to Set Up LPD/LPR Printing
When using the printing protocol Line Printer Daemon/Line Printer
Remote-Protokoll (LPD/LPR) , printing is done via a TCP/IP connec-
tion.
Mode of Operation
LPD/LPR consists of two components:
• Line Printer Daemon (LPD) refers to the process which receives
print jobs from the LPR client. LPD runs on the print server. Thus
the print server is called LPD server.
• Line Printer Remote (LPR) is the term for the process which
sends print jobs to a printer or respectively to a print queue. The
client (PC, etc.) which sends the print job is the LPR client and
must be equipped with the required software.
Procedure
Follow these steps if you want to print:
• ’Activating LPR on the Client’ 12.
• ’Setting up the Printer on the Client’ 12.
• ’Setting Up the Printer Port’ 13.
