Print Jobs and Print Data
Print Server User Manual Windows 77
Configuring Logical Printers via the InterCon-NetTool
Requirements
The InterCon-NetTool is installed on the client, see: 15.
You can adapt the assigned functions and printer ports to your
needs.
1. Start the InterCon-NetTool.
2. Double-click the print server in the device list.
The Properties dialog appears.
3. Select Configuration – Logical Printer.
4. Change the desired parameters, see: Table 11
76
.
5. Click OK to confirm.
The setting will be saved.
Assigning Logical Printers
Depending on your system, logical printers may be addressed in var-
ious ways. The assignment is done when you create printers on the
client for the printers connected to the print server ( 9). In Win-
dows, the respective TCP/IP ports are used instead of the logical
printers; see: ’TCP/IP-Port’ 161
TCP/IP Port TCP/IP port in accordance with the logical printer.
The following default values apply:
No. 1 = 9100 No. 5 = 9104
No. 2 = 9101 No. 6 = 9105
No. 3 = 9102 No. 7 = 9106
No. 4 = 9103 No. 8 = 9107
Printer Port Defines the port used by the logical printer for printing.
This parameter is only available for print server models with
several physical printer ports.
Binary PostScript Enables/disables the printing of binary PostScript files. 'Binary
PostScript' should be enabled if binary PostScript files are to be
printed in heterogeneous networks.
Parameters Description
