Set the aperture
Similar to other digital cameras the optimum sharpness is
achieved at an intermediary f-stop (such as f=16/22).
Lens settings
(focus, aperture)
4.1 … obtain the best sharpness (continued)
Focus on the lens manually and with the Focusing Assistant
Set the approximate distance on the lens first and then use the
Focusing Assistant to fine-tune sharpness. Repeat this process
once all other sharpness enhancements (lens data, rotation
point, distance setting, exposure: TDI Stages) are complete.
Exposure:
TDI Stages
Select less TDI Stages for wide-angle lenses
When using wide-angle lenses the angles at the edge
become extreme, so there is a loss in sharpness in these areas
of the image. Reducing TDI Stages allows a better alignment
and increased edge sharpness for these lenses.
Instruction Manual Seitz 6x17 Digital - version 4.05 - May 2013- © by Seitz Phototechnik AG / Switzerland www.roundshot.ch page 46
